AF3860-90D
2024-12-20
66kW @ 1800 RPM
- Model: AF3860-90D
- Displacement: 3.9L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Turbo & intercooling
- Number of Cylinders: 4
- Bore×Stroke: 102×118
- Compression ratio: 17.5：1
- Fuel consumption: 215 g/kW·h
- Lubricating oil capacity: 13 L
- Cooling system capacity: 6.5 L
- Electrical System: 24V
- Fly wheel: SAE3#SAE11.5〞
- Dry Weight: 380KG
- Dimensions (LxWxH): 810×700×850 mm
01
AF3860-75D
2024-12-20
55kW @ 1800 RPM
- Model: AF3860-75D
- Displacement: 3.9L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Turbocharged
- Number of Cylinders: 4
- Bore×Stroke: 102×118
- Compression ratio: 17.5：1
- Fuel consumption: 220 g/kW·h
- Lubricating oil capacity: 13 L
- Cooling system capacity: 6.5 L
- Electrical System: 24V
- Fly wheel: SAE3#SAE11.5〞
- Dry Weight: 380KG
- Dimensions (LxWxH): 810×700×850 mm
01
AF3860-61D
2024-12-20
44kW @ 1800 RPM
- Model: AF3860-61D
- Displacement: 3.9L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Naturally aspirated
- Number of Cylinders: 4
- Bore×Stroke: 102×118
- Compression ratio: 17.5：1
- Fuel consumption: 225 g/kW·h
- Lubricating oil capacity: 12.5 L
- Cooling system capacity: 6.5 L
- Electrical System: 24V
- Fly wheel: SAE3#SAE11.5〞
- Dry Weight: 350KG
- Dimensions (LxWxH): 810×680×800 mm
01
AF3860-53D
2024-12-20
39kW @ 1800 RPM
- Model: AF3860-53D
- Displacement: 3.9L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Naturally aspirated
- Number of Cylinders: 4
- Bore×Stroke: 102×118
- Compression ratio: 17.5：1
- Fuel consumption: 225 g/kW·h
- Lubricating oil capacity: 12.5 L
- Cooling system capacity: 6.5 L
- Electrical System: 24V
- Fly wheel: SAE3#SAE11.5〞
- Dry Weight: 350KG
- Dimensions (LxWxH): 810×680×800 mm
01
AF3860-78D
2024-12-20
57kW @ 1500 RPM
- Model: AF3860-78D
- Displacement: 3.9L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Turbocharged
- Number of Cylinders: 4
- Bore×Stroke: 102×118
- Compression ratio: 17.5：1
- Fuel consumption: 210 g/kW·h
- Lubricating oil capacity: 13 L
- Cooling system capacity: 6.5 L
- Electrical System: 24V
- Fly wheel: SAE3#SAE11.5〞
- Dry Weight: 380KG
- Dimensions (LxWxH): 810×700×850 mm
01
AF3860-65D
2024-12-20
48kW @ 1500 RPM
- Model: AF3860-65D
- Displacement: 3.9L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Turbocharged
- Number of Cylinders: 4
- Bore×Stroke: 102×118
- Compression ratio: 17.5：1
- Fuel consumption: 220 g/kW·h
- Lubricating oil capacity: 13 L
- Cooling system capacity: 6.5 L
- Electrical System: 24V
- Fly wheel: SAE3#SAE11.5〞
- Dry Weight: 380KG
- Dimensions (LxWxH): 810×700×850 mm
01
AF3860-53D
2024-12-20
39kW @ 1500 RPM
- Model: AF3860-53D
- Displacement: 3.9L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Naturally aspirated
- Number of Cylinders: 4
- Bore×Stroke: 102×118
- Compression ratio: 17.5：1
- Fuel consumption: 225 g/kW·h
- Lubricating oil capacity: 12.5 L
- Cooling system capacity: 6.5 L
- Electrical System: 24V
- Fly wheel: SAE3#SAE11.5〞
- Dry Weight: 350KG
- Dimensions (LxWxH): 810×680×800 mm
01
AF2540-38D
2024-12-20
28kW @ 1800 RPM
- Model: AF2540-38D
- Displacement: 2.5L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Naturally aspirated
- Number of Cylinders: 4
- Bore×Stroke: 90×100
- Compression ratio: 18：1
- Fuel consumption: 230 g/kW·h
- Lubricating oil capacity: 8 L
- Cooling system capacity: 2.5 L
- Electrical System: 12V
- Fly wheel: SAE4#SAE7.5〞
- Dry Weight: 220KG
- Dimensions (LxWxH): 750×555×680 mm
01
AF2270-28D
2024-12-20
20kW @ 1800 RPM
- Model: AF2270-28D
- Displacement: 2.3L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Naturally aspirated
- Number of Cylinders: 4
- Bore×Stroke: 85×95
- Compression ratio: 18：1
- Fuel consumption: 240 g/kW·h
- Lubricating oil capacity: 7.8 L
- Cooling system capacity: 2.2 L
- Electrical System: 12V
- Fly wheel: SAE4#SAE7.5〞
- Dry Weight: 220KG
- Dimensions (LxWxH): 750×555×680 mm
01
AF2540-39D
2024-12-20
29kW @ 1500 RPM
- Model: AF2540-39D
- Displacement: 2.5L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Turbocharged
- Number of Cylinders: 4
- Bore×Stroke: 90×100
- Compression ratio: 17.5：1
- Fuel consumption: 230 g/kW·h
- Lubricating oil capacity: 8 L
- Cooling system capacity: 2.5 L
- Electrical System: 12V
- Fly wheel: SAE4#SAE7.5〞
- Dry Weight: 240KG
- Dimensions (LxWxH): 750×600×735 mm
01
AF2540-35D
2024-12-20
26kW @ 1500 RPM
- Model: AF2540-35D
- Displacement: 2.5L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Turbocharged
- Number of Cylinders: 4
- Bore×Stroke: 90×100
- Compression ratio: 17.5：1
- Fuel consumption: 230 g/kW·h
- Lubricating oil capacity: 8 L
- Cooling system capacity: 2.5 L
- Electrical System: 12V
- Fly wheel: SAE4#SAE7.5〞
- Dry Weight: 240KG
- Dimensions (LxWxH): 750×600×735 mm
01
AF2540-29D
2024-12-18
21kW @ 1500 RPM
- Model: AF2540-29D
- Displacement: 2.5L
- Engine Type: In line, four stroke, direct injection, water cooled
- Aspiration: Naturally aspirated
- Number of Cylinders: 4
- Bore×Stroke: 90×100
- Compression ratio: 18：1
- Fuel consumption: 235 g/kW·h
- Lubricating oil capacity: 8 L
- Cooling system capacity: 2.5 L
- Electrical System: 12V
- Fly wheel: SAE4#SAE7.5〞
- Dry Weight: 220KG
- Dimensions (LxWxH): 750×555×680 mm
