AS35000-W0160 G-Drive Engine
W Type (818~1118kW)

AS35000-W0160 G-Drive Engine


1118kW @ 1500 RPM

  • Model: AS35000-W0160
  • Displacement: 35L
  • Engine Type: In line, four stroke, direct injection, water cooled
  • Aspiration: Turbo & intercooling
  • Number of Cylinders: 6
  • Bore×Stroke: 186×215
  • Compression ratio: 16：1
  • Fuel consumption: 195 g/kW·h
  • Lubricating oil capacity: 100L
  • Cooling system capacity: 78 L
  • Electrical System: 24V
  • Fly wheel: SAE0#SAE18〞
  • Dry Weight: 4000KG
  • Dimensions (LxWxH): 2429×1422×2019 mm
Contact us Download
product details
product description

description2

W Type (818~1118kW)

Model Engine Prime Power Genset Prime Power Governer Emission
AS35000-W0165 818kW @ 1500 RPM 720kWe @ 50Hz ECU Stage III
AS35000-W0164 882kW @ 1500 RPM 800kWe @ 50Hz ECU Stage III
AS35000-W0161 1018kW @ 1500 RPM 900kWe @ 50Hz ECU Stage III
AS35000-W0160 1118kW @ 1500 RPM 1000kWe @ 50Hz ECU Stage III

Advantages of AS Series G-Drive Engine

• AS Series Generator Drive Engine adopts microcomputer control system, good overall technical design, production and assembly are more in line with the standard technical requirements, and discard the technical design defects of the assembly unit.

• The engine uses a new combustor to increase the fuel injection pressure, improve the combustion process, and achieve environmental protection indicators: engine emissions meet non-road country III emission standards.

• The AS Series generator Drive Engine optimizes the design of the lubrication and cooling system, reduces the number of external pipelines and parts, and uses the whole brushless alternator to greatly improve the three leakage and greatly enhance the reliability.

• The engine has the advantages of large power, low fuel consumption, easy start, low emission, low vibration noise, easy maintenance and use.
